- AS 2047 Certified Performance
- Water Resistance: 500Pa
- Wind Pressure Resistance: 1500Pa
- Ultimate Strength: 3000Pa
- Low Air Infiltration
- Heavy-Duty Load Capacity
Built for strength and stability — up to 300kg for motorized doors and 600kg for manual sliding doors, ensuring effortless movement and lasting durability. - Secure Locking System
Equipped with BOGO sliding door locks, providing enhanced safety and smooth operation for both residential and commercial use. - Weather Sealing Excellence
Premium EPDM weather strips deliver outstanding air and water tightness, maintaining comfort and efficiency in all seasons. - Flexible Threshold Design
Choose between high-track or concealed-track options to match your architectural preference and functional needs — whether for elevated terraces or flush indoor transitions. - Refined Aesthetics
Sleek aluminum profiles with optional powder-coated finishes in custom colors, ensuring a perfect blend of modern design and performance. - Dimension of Frame
3200mm (Height) x 3000 mm (Width) x 138 mm (Thickness)
Certification & Quality Assurance
Our 138 Series Sliding Door meets the rigorous AS 2047 certification, guaranteeing top-tier performance for strength, weather resistance, and energy efficiency.
Profile Colors Option
- Classic colors: Matt Black, Light Grey, Monument, White
- Other colors: RAL Color, Dulux color, International Color Card
- Surface treatment : Powder coating, anodise, PVDF…
- Corrosion resistant, 10+ years warranty
Classic Colors
Glass Option
- AS1288, AS2208, 4666, Australia Certificate
- Thickness of single glass: 5-20mm
- Glass types: Single glass, Double glass, Triple glass, Laminated glass, Tinted glass, Hot bending glass, Frosted glass, Toughened glass, Low-e coated glass
- Special performance glass: Fireproof glass, Bulletproof glass，tinted, low-e, sound-proof and burglarproof
138 Series Sliding Door Lock
The 138 series sliding door handle lock series is specially engineered for slim-profile aluminum doors, offering a clean, modern look without compromising strength or security.
This model integrates an ergonomic handle for smooth, comfortable operation. Designed to complement minimalistic door frames, it provides seamless functionality and enhanced usability while maintaining a sleek appearance. Ideal for projects that require a more concealed or low-profile locking solution.
The simplified form factor allows it to blend discreetly into slim aluminum door systems, making it suitable for minimalist architectural styles.
FAQS
Yes, certified under AS 2047 with:
500Pa water resistance
low air infiltration
1500Pa wind pressure
3000Pa ultimate strength
Motorized version: up to 300kg
Manual version: up to 600kg
Ideal for oversized luxury sliding doors.
Features a reliable BOGO sliding door lock, suitable for high-security applications.
Two choices:
High track: better waterproof performance
Hidden track: minimalist look & barrier-free design
.
Yes, the entire frame uses EPDM to achieve excellent weather resistance.
Yes, this system is specifically designed for extra-large, heavy glass panels.
Yes. Low-E, triple glazing, and laminated options are available.
Yes, high-precision rollers ensure easy, quiet sliding no matter the weight.
